Partitioning
Individual compute nodes are grouped together into larger subsets of the cluster to form so called partitions.
The tables on this page list key attributes of MOGON’s partitions. You can also query this information using the following Slurm command:
scontrol show partition <name-of-partition>
For example:
scontrol show partition parallel
to show default, minimal, and maximal settings for reservation time, memory capacity, etc. of the parallel
partition.
MOGON NHR
Partition | Nodes | Limit | RAM | Intended Use |
---|---|---|---|---|
smallcpu | CPU-Nodes | 6 days | $\space256\thinspace\text{GB}$ $\space512\thinspace\text{GB}$ | for jobs using CPUs $\ll 128$ max. run. jobs per user: $3\text{k}$ |
parallel | CPU-Nodes | 6 days | $\space256\thinspace\text{GB}$ $\space512\thinspace\text{GB}$ | jobs using $\text{n}$ nodes, CPUs $\text{n}\times128$ for $\text{n}\in[1,2,\ldots]$ |
longtime | CPU-Nodes | 12 days | $\space256\thinspace\text{GB}$ $\space512\thinspace\text{GB}$ | long running jobs $\ge \text{6 days}$ |
largemem | CPU-Nodes | 6 days | $\space1024\thinspace\text{GB}$ | memory requirement |
hugemem | CPU-Nodes | 6 days | $\space2048\thinspace\text{GB}$ | memory requirement |
Partitions supporting Accelerators
Partition | Nodes | Limit | RAM | Intended Use |
---|---|---|---|---|
mi250 | AMD-Nodes | 6 days | $\space1024\thinspace\text{GB}$ | GPU requirement |
smallgpu | A40 | 6 days | $\space1024\thinspace\text{GB}$ | GPU requirement |
a100dl | A100 | 6 days | $\space1024\thinspace\text{GB}$ | GPU requirement |
a100ai | A100 | 6 days | $\space2048\thinspace\text{GB}$ | GPU requirement |
Private Partitions within MOGON NHR
Partition | Nodes | Limit | RAM | Accelerators | |
---|---|---|---|---|---|
topml | gpu0601 | 6 days | $1\thinspace\text{TB}$ | NVIDIA H100 80GB HBM3 | |
komet | floating Partition | 6 days | $256\thinspace\text{GB}$ | - | |
czlab | gpu0602 | 6 days | $1.5\thinspace\text{TB}$ | NVIDIA L40 |
MOGON II
- Only ~5% of nodes are available for small jobs (
n<<40
). - Each account has a
GrpTRESRunLimit
.
Check using sacctmgr -s list account <your_account> format=account,GRpTRESRunMin
, you can use sacctmgr -n -s list user $USER formatAccount%20 | grep -v none
to get your accounts. The default is cpu=22982400
, which is the equivalent of using 700 nodes for 12 hours in total:
Partition | Nodes | Limit | RAM | Interconnect | Intended Use |
---|---|---|---|---|---|
smp | z-nodes x-nodes | 5 days | $\space64\thinspace\text{GB}$ $\space96\thinspace\text{GB}$ $128\thinspace\text{GB}$ $192\thinspace\text{GB}$ $256\thinspace\text{GB}$ | Intel Omnipath | for jobs using CPUs $\text{n} \ll 40$ or $\text{n} \ll 64$ max. running jobs per user: $3\text{k}$ |
devel | z-nodes x-nodes | 4 hours | $\space64\thinspace\text{GB}$ $\space96\thinspace\text{GB}$ $128\thinspace\text{GB}$ | Intel Omnipath | max. 2 Jobs per User, max. 320 CPUs in total |
parallel | z-nodes x-nodes | 5 days | $\space64\thinspace\text{GB}$ $\space96\thinspace\text{GB}$ $128\thinspace\text{GB}$ $192\thinspace\text{GB}$ $256\thinspace\text{GB}$ | Intel Omnipath | jobs using $\text{n}$ nodes, CPUs $\text{n}\times40$ or $\text{n}\times64$ for $\text{n}\in[1,2,3,\ldots]$ |
bigmem | z-nodes x-nodes | 5 days | $384\thinspace\text{GB}$ $512\thinspace\text{GB}$ $1\thinspace\text{TB}$ $1.5\thinspace\text{TB}$ | Intel Omnipath | for jobs needing more than $256\thinspace\text{GB}$ of memory |
longtime | z-nodes x-nodes | 12 days | $\space64\thinspace\text{GB}$ $\space96\thinspace\text{GB}$ $128\thinspace\text{GB}$ $192\thinspace\text{GB}$ $256\thinspace\text{GB}$ $384\thinspace\text{GB}$ $512\thinspace\text{GB}$ $1\thinspace\text{TB}$ $1.5\thinspace\text{TB}$ | Intel Omnipath | for jobs needing more than 5 days walltime |
Partitions supporting Accelerators
Partition | Nodes | Limit | Interconnect | Accelerators | Comment |
---|---|---|---|---|---|
deeplearning | dgx-nodes | 18 hours | Infiniband | 8 Tesla V100-SXM2 per node | for access |
m2_gpu | s-nodes | 5 days | Infiniband | 6 GeForce GTX 1080 Ti per node | - |
Private Partitions within MOGON II
Partition | Nodes | Limit | RAM | Interconnect | Accelerators |
---|---|---|---|---|---|
himster2_exp | x0753 - x0794, x2001 - x2023 | 5 days | $96\thinspace\text{GB}$ | Intel OmniPath | - |
himster2_th | x2024 - x2320 | 5 days | $96\thinspace\text{GB}$ | Intel OmniPath | - |
Memory limits
The technical specification for RAM on our nodes (as described above) is slightly different from the memory that is effectively available. A small part is always going to be reserved for the operating system, the parallel file system, the scheduler, etc. Therefore, you find memory limits that might be relevant for a job—for example when specifying the --mem
option—in the table below.
Binary prefixes are often indicated as Ki, Mi, Gi, … (kibi, mebi, gibi) to distinguish them from their decimal counterparts (kilo, mega, giga). That is not the case for Slurm, though. Slurm uses the decimal prefixes, but always refers to units based on powers of 2 (so 1 kB corresponds to 1024 bytes).
To be consistent with Slurm’s documentation, we also stick to the standard SI prefixes despite the ambiguity.
You can use the SLURM command sinfo
to query all these limits. For example:
sinfo -e -o "%20P %16F %8z %.8m %.11l %18f" -S "+P+m"
The output returns a list of our partitions and
- information on their nodes (
allocated/idle/other/total
) - CPU specs of these nodes (
sockets:cores:threads
) - size of real memory in megabytes
- walltime limits for job requests
- and feature constraints.
MOGON NHR
At the moment of writing, for example, the output on MOGON NHR looks like this:
PARTITION NODES(A/I/O/T) S:C:T MEMORY TIMELIMIT
a100ai 1/2/1/4 2:64:2 1992000 6-00:00:00
a100dl 1/8/2/11 2:64:1 1016000 6-00:00:00
a40 1/6/0/7 2:64:1 1016000 6-00:00:00
czlab 0/1/0/1 2:64:1 1031828 6-00:00:00
hugemem 0/1/3/4 2:64:1 1992000 6-00:00:00
komet 355/43/34/432 2:64:1 248000 6-00:00:00
largemem 0/19/9/28 2:64:1 1016000 6-00:00:00
longtime 9/0/1/10 2:64:1 248000 12-00:00:00
longtime 10/0/0/10 2:64:1 504000 12-00:00:00
mi250 0/2/0/2 2:64:1 1016000 6-00:00:00
mod 167/4/5/176 2:64:1 504000 6-00:00:00
parallel 355/43/34/432 2:64:1 248000 6-00:00:00
parallel 167/4/5/176 2:64:1 504000 6-00:00:00
quick 355/43/34/432 2:64:1 248000 8:00:00
smallcpu 355/43/34/432 2:64:1 248000 6-00:00:00
topml 0/1/0/1 2:48:2 1547259 6-00:00:00
Memory [MB] | Number of Nodes |
---|---|
$248.000$ | 432 |
$504.000$ | 176 |
$1.016.000$ | 28 |
$1.992.000$ | 4 |
Memory [MB] | Number of Nodes |
---|---|
$1.016.000$ | 20 |
$1.992.000$ | 4 |
MOGON II
At the moment of writing the output on MOGON II looks like this:
PARTITION NODES(A/I/O/T) S:C:T MEMORY TIMELIMIT AVAIL_FEATURES
bigmem 8/5/19/32 2:16:2 354000 5-00:00:00 anyarch,skylake
bigmem 0/8/12/20 2:10:2 498000 5-00:00:00 anyarch,broadwell
bigmem 0/0/2/2 2:10:2 1002000 5-00:00:00 anyarch,broadwell
bigmem 0/2/0/2 2:16:2 1516000 5-00:00:00 anyarch,skylake
deeplearning 0/1/1/2 2:20:2 490000 18:00:00 anyarch,broadwell
devel 438/14/140/592 2:10:2 57000 4:00:00 anyarch,broadwell
devel 473/9/138/620 2:16:2 88500 4:00:00 anyarch,skylake
devel 99/23/46/168 2:10:2 120000 4:00:00 anyarch,broadwell
devel 60/16/44/120 2:16:2 177000 4:00:00 anyarch,skylake
devel 20/5/15/40 2:10:2 246000 4:00:00 anyarch,broadwell
devel 8/5/19/32 2:16:2 354000 4:00:00 anyarch,skylake
himster2_exp 1/57/7/65 2:16:2 88500 5-00:00:00 anyarch,skylake
himster2_interactive 1/1/0/2 2:16:2 88500 5-00:00:00 anyarch,skylake
himster2_th 272/7/17/296 2:16:2 88500 5-00:00:00 anyarch,skylake
kph_NT 0/14/2/16 2:10:2 246000 5-00:00:00 anyarch,broadwell
m2_gpu 20/5/5/30 2:12:2 115500 5-00:00:00 anyarch,broadwell
m2_gpu-compile 20/5/5/30 2:12:2 115500 1:00:00 anyarch,broadwell
m2_gputest 2/0/0/2 2:12:2 115500 5-00:00:00 anyarch,broadwell
parallel 438/14/140/592 2:10:2 57000 5-00:00:00 anyarch,broadwell
parallel 473/9/138/620 2:16:2 88500 5-00:00:00 anyarch,skylake
parallel 99/23/46/168 2:10:2 120000 5-00:00:00 anyarch,broadwell
parallel 60/16/44/120 2:16:2 177000 5-00:00:00 anyarch,skylake
parallel 20/5/15/40 2:10:2 246000 5-00:00:00 anyarch,broadwell
parallel 8/5/19/32 2:16:2 354000 5-00:00:00 anyarch,skylake
smp 438/14/140/592 2:10:2 57000 5-00:00:00 anyarch,broadwell
smp 473/9/138/620 2:16:2 88500 5-00:00:00 anyarch,skylake
smp 99/23/46/168 2:10:2 120000 5-00:00:00 anyarch,broadwell
smp 60/16/44/120 2:16:2 177000 5-00:00:00 anyarch,skylake
smp 20/5/15/40 2:10:2 246000 5-00:00:00 anyarch,broadwell
smp 8/5/19/32 2:16:2 354000 5-00:00:00 anyarch,skylake
Memory [MB] | Number of Nodes | Type |
---|---|---|
$\space57.000$ | 584 | broadwell |
$\space88.500$ | 576 | skylake |
$120.000$ | 120 | broadwell |
$177.000$ | 120 | skylake |
$246.000$ | 40 | broadwell |
Memory [MB] | Number of Nodes | Type |
---|---|---|
$\space\space354.000$ | 32 | skylake |
$\space\space498.000$ | 20 | broadwell |
$1.002.000$ | 2 | broadwell |
$1.516.000$ | 2 | skylake |
Hidden Partitions
Information on hidden partitions can be viewed by anyone. These partitions are set to be hidden to avoid cluttering the output for every poll - these partitions are “private” to certain projects / groups and of interest to these groups, only.
To visualize all jobs for a user in all partitions supply the -a
flag:
squeue -u $USER -a
Likewise sinfo
can be supplemented with -a
to gather informations. All other commands work without this flag as expected.
